Features:
Suitable Conditions:
Suitable for steer/trailer for long-distance transportation ,running on high-grade roadsDescription
Characteristic:
Improved tread design, High wear resistance and eccentric wear resistance .
Low rolling resistance , Save fuel consumption, Good handling quality
Suitable Condition:
Suitable for steer/trailer for long-distance transportation ,running on high-grade roads
Data table
| Size | Std. Rim | Load Index | Spd | Inflated Dimensions | Relative Pressure | Max.Load | ||
| PR | (mm) | KG | ||||||
| S.W. | O.D. | KPA | Single/Dual | |||||
| 11R22.5 | 16 | 8.25 | 146/143 | M | 279 | 1050 | 830 | 3000/2725 |
| 11R24.5 | 16 | 8.25 | 149/146 | M | 279 | 1104 | 830 | 3250/3000 |
| 205/75R17.5 | 16 | 6.00 | 124/122 | M | 205 | 753 | 750 | 1600/1500 |
| 215/75R17.5 | 16 | 6.00 | 126/124 | M | 212 | 767 | 700 | 1700/1600 |
| 235/75R17.5 | 16 | 6.75 | 132/130 | M | 233 | 797 | 775 | 2000/1900 |
| 225/70R19.5 | 14 | 6.75 | 128/126 | M | 226 | 811 | 760 | 1800/1700 |
| 265/70R19.5 | 16 | 7.50 | 140/138 | M | 262 | 867 | 775 | 2500/2360 |
| 245/70R19.5 | 16 | 7.50 | 135/133 | M | 248 | 833 | 830 | 2180/2060 |
| 265/70R19.5 | 16 | 7.50 | 140/138 | M | 262 | 867 | 775 | 2500/2360 |
| 255/70R22.5 | 16 | 7.50 | 140/137 | M | 255 | 930 | 830 | 2500/2300 |
| 275/70R22.5 | 16 | 8.25 | 148/145 | M | 276 | 958 | 900 | 3150/2900 |
| 295/75R22.5 | 16 | 9.00 | 146/143 | L | 298 | 1014 | 830 | 3000/2725 |
| 285/75R24.5 | 16 | 8.25 | 147/144 | L | 283 | 1056 | 830 | 3075/2800 |
