11R22.5 11R24.5 285/75R24.5 295/75R22.5
Features:
Suitable Conditions:
Suitable for steer/trailer position pf buses and light trucks running on highway
Description
Characteristic: High wear resistance,High cost performance,Excellent anti-side-skid character and good drainage character,Good handling quality
Suitable Condition: Suitable for steer/trailer position pf buses and light trucks running on highway
Data table
| Size | PR | Std. Rim | Load Index | Spd | Inflated Dimensions | Relative Pressure | Max.Load KG Single/Dual | |
| (mm) | ||||||||
| S.W. | O.D. | KPA | ||||||
| 11R22.5 | 14 | 8.25 | 144/142 | M | 279 | 1050 | 720 | 2800/2650 |
| 11R24.5 | 14 | 8.25 | 146/143 | M | 279 | 1100 | 720 | 3000/2725 |
| 285/75R24.5 | 14 | 8.25 | 144/141 | L | 283 | 1056 | 760 | 2800/2575 |
| 295/75R22.5 | 14 | 9.00 | 144/141 | L | 298 | 1014 | 760 | 2800/2575 |
