4.10/3.50-4 4.80/4.00-8 11x4.00-4 11x4.00-5 13x5.00-6 13x5.00-6 13x6.50-6 15x6.00-6 16x6.50-8 16x7.50-8 18x6.50-8 18x7.00-8 18x8.50-8 18x8.50-10 18x9.50-8 18x10.50-10 20x8.00-8 20x8.00-10 20x10.00-8 20x10.00-10 23x8.50-12 23x9.50-12
Features:
Suitable Conditions:
Turf Tyres working for Lawn & Garden
Description
Data table
| Size | PLY | TT/TL | Pattern | Tread Depth(mm) | Rim Width(in) | SW(mm) | OD(mm) | MAX Load(Lbs) | PSI |
| 4.10/3.50-4 | 2 | TL | P332 | 3.0 | 3.25 | 99 | 271 | 230 | 24 |
| 4.10/3.50-4 | 4 | TL | P332 | 3.0 | 3.25 | 99 | 271 | 350 | 50 |
| 4.80/4.00-8 | 2 | TL | P332 | 3.5 | 3.75 | 119 | 421 | 435 | 20 |
| 4.80/4.00-8 | 4 | TL | P332 | 3.5 | 3.75 | 119 | 421 | 670 | 42 |
| 11x4.00-4 | 2 | TL | P332 | 3.0 | 3.25 | 105 | 273 | 215 | 22 |
| 11x4.00-4 | 4 | TL | P332A | 3.0 | 3.25 | 105 | 273 | 330 | 46 |
| 11x4.00-5 | 2 | TL | P332A | 3.0 | 3.00 | 102 | 276 | 210 | 22 |
| 11x4.00-5 | 4 | TL | P332 | 3.0 | 3.00 | 102 | 276 | 325 | 46 |
| 13x5.00-6 | 2 | TL | P332 | 3.0 | 4.50 | 128 | 311 | 295 | 20 |
| 13x5.00-6 | 4 | TL | P332 | 3.0 | 4.50 | 128 | 316 | 440 | 40 |
| 13x5.00-6 | 6 | TL | P332 | 3.0 | 3.50 | 128 | 316 | 525 | 46 |
| 13x6.50-6 | 4 | TL | P332 | 3.5 | 5.00 | 160 | 333 | 460 | 28 |
| 15x6.00-6 | 2 | TL | P332 | 6.0 | 4.50 | 155 | 363 | 365 | 14 |
| 15x6.00-6 | 4 | TL | P332 | 6.0 | 4.50 | 160 | 380 | 570 | 30 |
| 15x6.00-6 | 6 | TL | P332 | 6.0 | 4.50 | 160 | 380 | 595 | 45 |
| 16x6.50-8 | 2 | TL | P332 | 7.1 | 5.375 | 165 | 395 | 415 | 14 |
| 16x6.50-8 | 4 | TL | P332 | 7.1 | 5.375 | 165 | 400 | 620 | 28 |
| 16x6.50-8 | 6 | TL | P332 | 7.1 | 5.375 | 167 | 412 | 785 | 42 |
| 16x7.50-8 | 2 | TL | P332 | 7.1 | 5.375 | 182 | 415 | 475 | 12 |
| 16x7.50-8 | 4 | TL | P332 | 7.1 | 5.375 | 182 | 415 | 680 | 24 |
| 16x7.50-8 | 6 | TL | P332 | 7.1 | 5.375 | 182 | 415 | 900 | 36 |
| 18x6.50-8 | 4 | TL | P332 | 4.0 | 5.00 | 165 | 455 | 770 | 28 |
| 18x7.00-8 | 4 | TL | P332 | 7.0 | 5.375 | 177 | 450 | 785 | 26 |
| 18x7.00-8 | 6 | TL | P332 | 7.0 | 5.375 | 450 | 177 | 990 | 36 |
| 18x8.50-8 | 2 | TL | P332 | 7.1 | 7.00 | 210 | 446 | 515 | 10 |
| 18x8.50-8 | 4 | TL | P332 | 7.1 | 7.00 | 210 | 449 | 815 | 22 |
| 18x8.50-10 | 4 | TL | P332 | 7.1 | 7.00 | 206 | 478 | 795 | 22 |
| 18x9.50-8 | 2 | TL | P332 | 5.0 | 7.00 | 223 | 462 | 695 | 12 |
| 18x9.50-8 | 4 | TL | P332 | 5.0 | 7.00 | 223 | 465 | 1040 | 24 |
| 18x9.50-8 | 6 | TL | P332 | 5.0 | 7.00 | 223 | 465 | 1320 | 36 |
| 18x10.50-10 | 4 | TL | P332 | 8.5 | 8.50 | 250 | 485 | 990 | 20 |
| 20x8.00-8 | 2 | TL | P332 | 3.5 | 6.50 | 207 | 507 | 600 | 10 |
| 20x8.00-8 | 4 | TL | P332 | 3.5 | 6.50 | 207 | 507 | 950 | 22 |
| 20x8.00-10 | 4 | TL | P332 | 8.0 | 7.00 | 216 | 505 | 895 | 24 |
| 20x8.00-10 | 6 | TL | P332 | 8.0 | 6.00 | 216 | 505 | 1200 | 35 |
| 20x10.00-8 | 2 | TL | P332 | 7.1 | 7.00 | 236 | 495 | 750 | 10 |
| 20x10.00-8 | 4 | TL | P332 | 7.1 | 7.00 | 236 | 500 | 1190 | 22 |
| 20x10.00-8 | 6 | TL | P332 | 7.1 | 8.00 | 249 | 508 | 1545 | 34 |
| 20x10.00-10 | 4 | TL | P332 | 8.0 | 8.00 | 243 | 505 | 1160 | 22 |
| 20x10.00-10 | 6 | TL | P332 | 8.0 | 8.00 | 243 | 505 | 1245 | 36 |
| 23x8.50-12 | 4 | TL | P332 | 9.8 | 7.00 | 206 | 579 | 1120 | 22 |
| 23x8.50-12 | 6 | TL | P332 | 9.8 | 7.00 | 206 | 594 | 1445 | 34 |
| 23x9.50-12 | 2 | TL | P332 | 5.0 | 7.00 | 232 | 580 | 920 | 12 |
| 23x9.50-12 | 4 | TL | P332 | 5.0 | 7.00 | 232 | 580 | 1380 | 24 |
| 23x10.50-12 | 2 | TL | P332 | 9.8 | 8.50 | 250 | 585 | 890 | 10 |
| 23x10.50-12 | 4 | TL | P332 | 9.8 | 8.50 | 250 | 585 | 1340 | 20 |
| 23x10.50-12 | 6 | TL | P332 | 9.8 | 8.50 | 217 | 471 | 1320 | 36 |
| 24x12.00-12 | 4 | TL | P332 | 9.8 | 10.50 | 295 | 606 | 1710 | 20 |
| 24x12.00-12 | 6 | TL | P332 | 9.8 | 10.50 | 295 | 615 | 2260 | 32 |
| 24x12.00-12 | 8 | TL | P332 | 9.8 | 10.50 | 293 | 610 | 2910 | 50 |
| 26x12.00-12 | 4 | TL | P332 | 9.8 | 10.50 | 312 | 650 | 1780 | 20 |
| 26x12.00-12 | 6 | TL | P332 | 9.8 | 10.50 | 310 | 655 | 2450 | 35 |
| 26x12.00-12 | 8 | TL | P332 | 9.8 | 10.50 | 310 | 655 | 3020 | 50 |
